This 2-bit noninverting translator uses two separate configurable power-supply rails. The A port is designed to track VCCA. VCCA accepts any supply voltage from 1.2 V to 3.6 V. The B port is designed to track VCCB. VCCB accepts any supply voltage from 1.65 V to 5.5 V. This allows for universal low-voltage bidirectional translation between any of the 1.2-V, 1.5-V, 1.8-V, 2.5-V, 3.3-V, and 5-V voltage nodes. VCCA should not exceed VCCB.

When the output-enable (OE) input is low, all outputs are placed in the high-impedance state.

This device is fully specified for partial-power-down applications using Ioff. The Ioff circuitry disables the outputs, preventing damaging current backflow through the device when it is powered down.

To ensure the high-impedance state during power up or power down, OE should be tied to GND through a pulldown resistor; the minimum value of the resistor is determined by the current-sourcing capability of the driver.

NanoFree? technology is a major breakthrough in IC packaging concepts, using the die as the package.

• 最新年份到貨 TI德州代理
• 保證原裝正品，價格優(yōu)勢
•

• 歡迎前來洽談訂購！
• 深圳市雙利電子有限公司
• 銷售部: 0755-8256 5693
• 傳 真：0755-82565053
• 手 機：13510133095
• Q Q：494581847 754034294
• 聯(lián)系人：陳先生
• 公司:深圳市福田區(qū)華強廣場D座20i
